100G QSFP28 Passive Copper Cable
Name:

100G QSFP28 Passive Copper Cable

Class:
Direct Attach Cable (DAC)
Type:
100G QSFP28 Passive Copper Cable

100G QSFP28 Passive Copper Cable Specification


Fiberer Rohs

Description

The 100GE QSFP28 cable assemblies are high performance, cost effective I/O solutions for LAN, HPC and SAN. The high speed cable assemblies meet and exceed 100 Gigabit Ethernet, InfiniBand EDR and temperature requirements for performance and reliability. The cables are compliant with SFF-8436 specifications and provide connectivity between devices using QSFP ports.


100G QSFP28 Passive Copper Cable

Features

 QSFP28 conforms to the Small Form Factor SFF8665

 4-Channel Full-Duplex Passive Copper Cable Transceiver

 Support for multi-gigabit data rates: 25.78Gb/s (per channel)

 Maximum aggregate data rate: 100Gb/s (4 x 25.78Gb/s)

 IEEE 802.3bj 100GEBASE-CR4

 Copper link length up to 3m

 Power Supply :+3.3V

 Low crosstalk

 I2C based two-wire serial interface for EEPROM signature which can be customized

 Operating Temperature: 0~ 70 °C

 RoHS Compliant




Standards Compliance

 IEEE 802.3bj

 InfiniBand EDR

 QSFP28 MSA

 RoHS Compliant




Applications

 100 Gigabit Ethernet

 Fiber Channel over Ethernet

 Data storage and communication industry

 Switch / router / HBA

 Enterprise network

 SAN

 Data Center Network











Packaging & Labeling
To protect each of product, Fiberer will use firm and secure Package, and common use Fiberer Label if customer not remark.
It is available to use custmized labeling and packaging for customer request.

Shipment
All shipment will be succssful to arrive customer's address. Fiberer try our best to let the shipment fast for customers, and the common express is by air of Fedex, DHL, UPS, EMS and TNT.
If the customer pay Fiberer the shipment charge, it will use Fiberer express account for the shipment, otherwise it need to use the customer's express account.

Customized & OEM
Fiberer always do Customized for customer's request successfully, It is available for Customized & OEM.


Quality Assurance:  assure 100% best quality.
(Fiberer assure 100% best quality.the term will be signed on order and invoice,match the safety of international business law.)    Customer Reviews
